Card Edge Connectors | Farnell® Ireland

Farnell offers a wide range of card edge connectors designed for reliable, high-density PCB connections. These connectors enable secure mating with printed circuit board edges, supporting high-speed signal transmission and power delivery.

Card edge connectors are precision-engineered connectors that interface directly with the edge of a printed circuit board. They provide consistent electrical contact across multiple pins while maintaining mechanical stability, making them suitable for memory modules, expansion cards and modular systems.

Applications

Motherboards and add-on cards
Industrial control systems
Telecommunication equipment

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price (inc VAT)	Mezzanine Connector Type	Card Edge Connector Type	Card Type	No. of Contacts	Card Thickness	Pitch Spacing	No. of Contacts	Gender	Connector Mounting	Connector Body Orientation	No. of Rows	Contact Termination Type	Contact Material	Contact Plating	Contact Plating - Mating Side	Connector Body Material	Product Range

ME10056334B1A01	3765448 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 56 Contacts Straddle Mount Straight	Each	1+ €3.700(€4.551) 10+ €3.150(€3.8745) 100+ €2.670(€3.2841)	-	Dual Side	-	-	1.57mm	-	56 Contacts	-	Straddle Mount	Straight	-	Solder	Copper Alloy	-	0.76µm Gold Plated Contacts	Thermoplastic Body	Mini CE
2358256-4	3651690 RoHS	TE CONNECTIVITY Card Edge Connector Single Side 1.57 mm 50 Contacts Through Hole Mount Right Angle	Each	1+ €7.710(€9.4833) 10+ €7.030(€8.6469) 100+ €6.090(€7.4907)	-	Single Side	-	-	1.57mm	-	50 Contacts	-	Through Hole Mount	Right Angle	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Thermoplastic, Glass Filled Body	-
10142333-10033MLF	3765419 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector PCIe Dual Side 1.57 mm 164 Contacts Through Hole Mount Straight	Each	1+ €6.130(€7.5399) 10+ €5.210(€6.4083) 100+ €4.330(€5.3259)	-	Dual Side	-	-	1.57mm	-	164 Contacts	-	Through Hole Mount	Straight	-	Solder	Copper Alloy	-	0.76µm Gold Plated Contacts	Thermoplastic, Glass Filled Body	-
SE1820023111111	3765458 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.6 mm 8 (Power) 200 (Signal) Contacts Surface Mount	Each	1+ €10.630(€13.0749) 10+ €9.040(€11.1192) 25+ €8.470(€10.4181) 100+ €7.680(€9.4464)	-	Dual Side	-	-	1.6mm	-	8 (Power), 200 (Signal) Contacts	-	Surface Mount	Straight	-	Solder	Copper Alloy	-	0.76µm Gold Plated Contacts	Thermoplastic Body	SE
2340165-1	3651696 RoHS	TE CONNECTIVITY Card Edge Connector Dual Side 1.57 mm 8 (Power) 84 (Signal) Contacts Straddle Mount	Each	1+ €16.410(€20.1843) 10+ €13.940(€17.1462) 25+ €13.060(€16.0638) 100+ €12.440(€15.3012)	-	Dual Side	-	-	1.57mm	-	8 (Power), 84 (Signal) Contacts	-	Straddle Mount	Straight	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Thermoplastic, Glass Filled Body	HD+
MEC1-140-02-F-D-A	3659970 Data Sheet RoHS	SAMTEC Card Edge Connector Dual Side 1.57 mm 80 Contacts Surface Mount Straight	Each	1+ €4.290(€5.2767) 10+ €4.200(€5.166)	-	Dual Side	-	-	1.57mm	-	80 Contacts	-	Surface Mount	Straight	-	Solder	Beryllium Copper	-	3µ" Gold Plated Contacts	LCP (Liquid Crystal Polymer) Body	MEC1
10146070-112Y1LF	3765422 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector PCIe Dual Side 1.57 mm 98 Contacts Surface Mount Straight	Each	1+ €8.390(€10.3197) 10+ €7.130(€8.7699) 100+ €6.060(€7.4538) 250+ €5.230(€6.4329)	-	Dual Side	-	-	1.57mm	-	98 Contacts	-	Surface Mount	Straight	-	Solder	Copper Alloy	-	0.76µm Gold Plated Contacts	LCP (Liquid Crystal Polymer) Body	-
G97R24232HR	3935424 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 124 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €5.410(€6.6543) 10+ €4.590(€5.6457) 25+ €4.460(€5.4858) 100+ €4.330(€5.3259)	-	Dual Side	-	-	1.57mm	-	124 Contacts	-	Surface Mount	Right Angle	-	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Stainless Steel Body	Mini Cool Edge Series
G97V24332HR	3935435 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 124 Contacts Surface Mount Straight	Each (Supplied on Cut Tape) Cut Tape	1+ €5.950(€7.3185) 10+ €5.870(€7.2201) 25+ €5.800(€7.134) 100+ €5.720(€7.0356)	-	Dual Side	-	-	1.57mm	-	124 Contacts	-	Surface Mount	Straight	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Stainless Steel Body	Mini Cool Edge Series
G97V26332HR	3935438 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 148 Contacts Surface Mount Straight	Each (Supplied on Cut Tape) Cut Tape	1+ €6.590(€8.1057) 10+ €6.450(€7.9335) 25+ €6.310(€7.7613) 100+ €6.170(€7.5891)	-	Dual Side	-	-	1.57mm	-	148 Contacts	-	Surface Mount	Straight	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Stainless Steel Body	Mini Cool Edge Series
G42V15332HR	3935420 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 50 Contacts Surface Mount Straight	Each (Supplied on Cut Tape) Cut Tape	1+ €3.710(€4.5633) 10+ €3.160(€3.8868) 100+ €2.560(€3.1488)	-	Dual Side	-	-	1.57mm	-	50 Contacts	-	Surface Mount	Straight	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Stainless Steel Body	Mini Cool Edge Series
G97R26312HR	3935427 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector Dual Side 1.57 mm 148 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €9.350(€11.5005) 10+ €7.950(€9.7785) 25+ €7.450(€9.1635) 100+ €6.210(€7.6383)	-	Dual Side	-	-	1.57mm	-	148 Contacts	-	Surface Mount	Right Angle	-	Solder	Copper Alloy	-	30µ" Gold Plated Contacts	Stainless Steel Body	Mini Cool Edge Series
009159004061916	2347864 Data Sheet RoHS Date/Lot Code	KYOCERA AVX Card Edge Connector Dual Side 1.6 mm 4 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	10+ €0.724(€0.8905) 50+ €0.592(€0.7282) 100+ €0.564(€0.6937) 250+ €0.528(€0.6494)	-	Dual Side	-	-	1.6mm	2mm	4 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Phosphor Bronze	-	Tin Plated Contacts	Nylon 4.6 (Polyamide 4.6) Body	00-9159 Series
1-2199119-5	2377467 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 67 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €1.760(€2.1648) 30+ €1.580(€1.9434) 90+ €1.540(€1.8942) 240+ €1.440(€1.7712)	-	Dual Side	-	-	-	0.5mm	67 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Thermoplastic Body	M.2 (NGFF)
PCIE-064-02-F-D-TH	1753907 Data Sheet RoHS	SAMTEC Card Edge Connector PCIe Dual Side PCI Express 1.57 mm 64 Contacts Through Hole Mount	Each	1+ €1.980(€2.4354) 10+ €1.850(€2.2755) 100+ €1.430(€1.7589) 250+ €1.390(€1.7097)	-	Dual Side	PCI Express	-	1.57mm	1mm	64 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	1µ" Gold Plated Contacts	Nylon 6.6 (Polyamide 6.6) Body	-
PCIE-164-02-F-D-TH	1753909 Data Sheet RoHS	SAMTEC Card Edge Connector PCIe Dual Side PCI Express 1.57 mm 164 Contacts Through Hole Mount	Each	1+ €3.270(€4.0221) 10+ €3.010(€3.7023) 100+ €2.300(€2.829) 250+ €2.210(€2.7183)	-	Dual Side	PCI Express	-	1.57mm	1mm	164 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	1µ" Gold Plated Contacts	Nylon 6.6 (Polyamide 6.6) Body	-
10018783-11111TLF	1144436 Data Sheet RoHS	AMPHENOL COMMUNICATIONS SOLUTIONS Card Edge Connector PCI Dual Side 1.57 mm 64 Contacts Through Hole Mount Straight	Each	1+ €1.350(€1.6605) 10+ €1.130(€1.3899) 100+ €0.938(€1.1537) 250+ €0.878(€1.0799)	-	Dual Side	-	-	1.57mm	1mm	64 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Nylon (Polyamide) Body	FCI 10018783
PCIE-098-02-F-D-TH	1753908 Data Sheet RoHS	SAMTEC Card Edge Connector PCIe Dual Side PCI Express 1.57 mm 98 Contacts Through Hole Mount	Each	1+ €4.100(€5.043) 10+ €3.270(€4.0221) 100+ €2.430(€2.9889) 250+ €2.380(€2.9274)	-	Dual Side	PCI Express	-	1.57mm	1mm	98 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	1µ" Gold Plated Contacts	Nylon 6.6 (Polyamide 6.6) Body	-
2199119-3	2377471 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 67 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €1.310(€1.6113) 30+ €1.180(€1.4514) 90+ €1.150(€1.4145) 240+ €1.080(€1.3284)	-	Dual Side	-	-	-	0.5mm	67 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Thermoplastic Body	M.2 (NGFF)
5530843-3	1557016 RoHS Date/Lot Code	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 1.85 mm 36 Contacts Through Hole Mount Straight	Each	1+ €4.050(€4.9815) 10+ €3.100(€3.813) 100+ €2.530(€3.1119) 250+ €2.400(€2.952)	-	Dual Side	-	-	1.85mm	2.54mm	36 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	30µ" Gold Plated Contacts	PET (Polyester), Glass Filled Body	Standard Edge II
PCIE-036-02-F-D-TH	1753906 Data Sheet RoHS	SAMTEC Card Edge Connector PCIe Dual Side PCI Express 1.57 mm 36 Contacts Through Hole Mount	Each	1+ €1.800(€2.214) 10+ €1.490(€1.8327) 100+ €1.170(€1.4391) 250+ €1.040(€1.2792)	-	Dual Side	PCI Express	-	1.57mm	1mm	36 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	1µ" Gold Plated Contacts	Nylon 6.6 (Polyamide 6.6) Body	-
2199119-4	2377468 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 67 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €2.050(€2.5215) 30+ €1.780(€2.1894) 90+ €1.740(€2.1402) 240+ €1.690(€2.0787)	-	Dual Side	-	-	-	0.5mm	67 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Thermoplastic Body	M.2 (NGFF)
2199230-8	2377475 Data Sheet RoHS	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 67 Contacts Surface Mount Right Angle	Each (Supplied on Cut Tape) Cut Tape	1+ €2.120(€2.6076) 25+ €1.420(€1.7466) 75+ €1.390(€1.7097) 200+ €1.350(€1.6605)	-	Dual Side	-	-	-	0.5mm	67 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Copper Alloy	-	15µ" Gold Plated Contacts	Thermoplastic Body	M.2 (NGFF)
5-5530843-0	2396188 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - AMP Card Edge Connector Dual Side 1.85 mm 20 Contacts Through Hole Mount Straight	Each	1+ €2.910(€3.5793) 10+ €2.360(€2.9028) 100+ €2.070(€2.5461) 250+ €1.810(€2.2263)	-	Dual Side	-	-	1.85mm	2.54mm	20 Contacts	-	Through Hole Mount	Straight	2Rows	Solder	Phosphor Bronze	-	30µ" Gold Plated Contacts	PET (Polyester), Glass Filled Body	Standard Edge II
009159010061916	2668413 Data Sheet RoHS Date/Lot Code	KYOCERA AVX Card Edge Connector Dual Side 1.6 mm 10 Contacts Surface Mount Right Angle	Each	1+ €1.350(€1.6605) 10+ €1.070(€1.3161) 100+ €0.853(€1.0492) 500+ €0.761(€0.936)	-	Dual Side	-	-	1.6mm	2mm	10 Contacts	-	Surface Mount	Right Angle	2Rows	Solder	Phosphor Bronze	-	Tin Plated Contacts	Nylon 4.6 (Polyamide 4.6) Body	00-9159 Series
