OXLEY  LS/B1/093 WHITE  SOCKET, TEST POINT, WHITE

OXLEY LS/B1/093 WHITE
Technical Data Sheet (331.68KB) EN See all Technical Docs

Image is for illustrative purposes only. Please refer to product description.

Product Overview

The SMOX series surface-mount Oxley Test Point with a compatible mating socket and is suitable for a range of applications. Due to the unique nature of the SMOX connection system, it represents the only surface-mount test point with a specially designed socket for easy low contact resistance and gentle detachment, the applications and potential uses are limitless. Requiring a minimum pad size of only 2mm and being a single-pole device, the SMOX can be placed accurately by any pick and place machine in even the most congested designs. The socket is normally used with the recommended PTFE insulated sleeve but for those very close pitch designers, this can be replaced with alternative insulation techniques. Detecting and localising board faults is an obvious application, where the ability to quickly and individually identify faulty components, cracked solder joints or short circuits can save time of testing via an edge mounted connector or under a microscope.
  • Unique retention mechanism enhances reliability through low stress connections
  • Minimum contact resistance (<2mR) through 8 points of contact
  • Chamfer design allows excellent solder fillets to be formed
  • Award winning kinematic design allows rapid connection/disconnection
  • Proven application through Snaplox range of test points
  • Hand or automatic assembly
  • Gold plated SMOX Test Point for low contact resistance and durability
  • Square or round solder pads can be used, with a minimum pad size of 2mm diameter

Product Information

Test Probe Type:
-
Test Probe Functions:
-
Accuracy %:
-
For Use With:
-
Product Range:
SMOX Series
Contact Plating:
Silver Plated Contacts
Operating Temperature Min:
-55 °C
Contact Material:
Copper
Operating Temperature Max:
125 °C
Contact Resistance:
2 mohm
SVHC:
No SVHC (17-Dec-2015)

Find similar products  grouped by common attribute

Applications

  • Test & Measurement

Legislation and Environmental

Country of Origin:
Great Britain

Country in which last significant manufacturing process was carried out

RoHS Compliant:
Yes
Tariff No:
85366990
Weight (kg):
.001251
