KEYSIGHT TECHNOLOGIES  U1252B  Digital Multimeter, U1250 Series, True RMS, 50000 Count, Auto/Manual Ranging

Manufacturer Part No:
U1252B
Order Code:
1780319
Product Range
U1250 Series
Technical Datasheet:
See all Technical Docs
KEYSIGHT TECHNOLOGIES U1252B
KEYSIGHT TECHNOLOGIES U1252B
360°

Image is for illustrative purposes only. Please refer to product description.

Product Overview

This handheld digital multimeters enable you to check more with wider measurement ranges. It features true RMS readings on their 10,000-count displays. The adjustable backlighting allows you to complete your jobs even in subdued lighting conditions, or to simply prolong battery life. Your maintenance tasks are greatly simplified due to the built-in switch counter, harmonic ratio, dual and differential temperature capabilities, with just a press of the button. The meter has a high safety rating with CAT III 1000 V and CAT IV 600 V protection and are certified to CE and CSA standards.
  • 10,000-count display
  • 0.09% basic DCV accuracy
  • True RMS AC measurement
  • Basic functions - ACV, DCV, ACI, DCI, resistance, frequency, diode, continuity tests
  • Advanced functions - Capacitance, temperature, MINMAX recording
  • Adjustable backlighting - 2 intensity levels
  • Over mould body casing
  • Manual data logging
  • Built-in switch counter, harmonic ratio

Product Information

DMM Functions:
Current, Voltage, Capacitance, Frequency, Resistance, Temperature
Current Measure AC Max:
10A
Current Measure DC Max:
10A
Voltage Measure AC Max:
1kV
Voltage Measure DC Max:
1kV
Resistance Measure Max:
0.5Gohm
DMM Response Type:
True RMS
Display Count:
50000
No. of Digits:
5
Range Selection:
Auto, Manual
Warranty:
3 Years
Product Range:
U1250 Series
Manufacturers Warranty:
3 Years
SVHC:
No SVHC (15-Jun-2015)

Find similar products  grouped by common attribute

Applications

  • Industrial
  • Maintenance & Repair
  • Test & Measurement

Contents

Quick Start Guide, Certificate of Calibration (CoC), test probe leads, 4 x 1.5 V batteries

Legislation and Environmental

Country of Origin:
Malaysia

Country in which last significant manufacturing process was carried out

Tariff No:
90303100
Weight (kg):
3
